CB500X (2016 - 2018)
Complete MadStad Adjustable Windshield System for your Honda CB500X (2016 - 2018)
Transform your ride
MadStad's patented mounting system allows riders to adjust the height and angle of their motorcycle windshield resulting in much smoother airflow, better wind protection and a more comfortable ride than any fixed windshield can provide.
What's included in the kit
Our complete drop-in system is custom-made for your bike and includes everything needed to mount and position the shield.
Your bike will not require any modification.
- A set of MadStad adjustable brackets
- The acrylic windshield
- Pair of acrylic side deflectors
The custom shield bolts to the brackets out in front of your instrument cluster. With the shield separated from the front of the bike you can adjust it for the optimum height, angle and airflow. This lets you set the shield for your particular height and riding position while pulling lots of air underneath it which is critical for smooth comfortable wind protection.
Riding is believing
With the windshield separated from the fairing riders now have control over the height and angle of the shield to eliminate the vacuum that is the primary cause of most turbulence. The result? Smooth airflow placed exactly where it’s desired. Most customers have found that they can actually get better wind protection with our smaller adjustable shield rather than a larger fixed one. You don't have to compromise wind protection to enjoy the open-air motorcycling experience!
Size and Color
While the MadStad windshield systems are fully adjustable, we recommend starting with the appropriate shield size relative to rider height.
|RIDER HEIGHT||SHIELD SIZE|
|5'8" to 5'11" (173 - 181 cm)||18" (450 mm)|
|6'0" to 6'3" (183 - 190 cm)||20" (500 mm)|
|6'4" and taller (193+ cm)||22" (550 mm)|
These are general recommendations and can vary depending on your inseam, seat height and riding position. We can also accommodate extra short or tall riders by special request.
All MadStad windshields are made from 3/16" (4.5 mm) thick cast acrylic and are available in six different tint colors. See photos bar for comparison image.
If you are not 100% satisfied with your purchase return it within 30 days. See our return policy details under the FAQ page and buy with confidence.
Here is what Daniel S. posted about his new Madstad CB500X - 2016 windshield system: 2/27/18 "here’s my update on the MADSTAD system, installed today...along with my panniers. I’m 5’ 11” w/ 31.5” inseam. MADSTAD screen reduced wind noise about 75%. Buffeting reduced almost 100%. I think the system looks nice on the bike, YMMV. It’s definitely not a big cruiser screen, but just large enough to do the job, along with the very effective up/down/slanting adjustments of course. I wear a SHOEI full face helmet. VERY pleased on the longish test ride home…25 to a sustained 85 MPH. Whew…thank goodness!!!"
